Easy-to-Make Drying Trays – Chelsea Green Publishing

Looking for a new way to enjoy your harvest well into the winter months? If you said, yes, then this one’s for you!

By following this simple tutorial, you can expand the lifespan of fruits, vegetables, mushrooms, and even herbs. It’s not only easy, environmentally friendly, and inexpensive — it also means you can enjoy the benefits of your garden all year long.

The following is an excerpt from Preserving Food Without Freezing or Canning by The Gardeners & Farmers of Terre Vivante. It has been adapted for the web.

Food is usually dried on a flat surface, such as a tray or screen, using a natural or artificial heat source. Solar drying is obviously the preferred method because it consumes only the sun’s energy and that energy is free. Trays should be placed in a dry, well-ventilated spot, generally out of the direct sun, or in specially designed solar dryers.

In lieu of natural sunshine, we can take advantage of the heat generated by a radiator, kitchen range, wood stove, or oven. If all these are lacking, we can settle for a low-wattage electric food dehydrator. Several models are available for home use.

Variation 1: Screened Drying Tray (60” x 20”)


  • Square battens (cross section 1.25″ x 1.25″)
  • Flat battens (cross section 1⁄8″ x 1.25″)
  • 20″-wide roll of galvanized metal or rigid plastic screen with fine mesh (25–50 mm or 1–2 sq. in.)
  • Nails (2″ and 1″ long)


  1. First assemble the square battens to form a frame sixty inches long by twenty inches wide. To make the frame more rigid, add one or two square battens across the middle. Hammer the frame together with 2-inch nails.
  2. Unroll the screening and flatten it against the frame using the flat battens to hold it in place.
  3. Fasten with 1-inch nails. This creates the bottom of the tray.
  4. The tray is now ready to use. Note that the trays can be stacked to save space.

Henry Rouy, Cournon-D’Auvergne

Variation 2: Small Multipurpose Dryer (for those with limited space)


  • Two 24″ x 2.5″ boards
  • Two 14″ x 2.5″ boards
  • Small wooden laths (strips)
  • Small nails


This is a basket that can be hung from a beam or a nail, in the cellar or kitchen. It is very simple to make.

  1. Make the sides of the basket with the four boards. Then nail the small wooden laths three-quarters of an inch apart to make the bottom.
  2. To make the handle, add two small boards of the same length as the basket to each side. Connect them with a round stick.
  3. You can dry cheese, mushrooms, prunes, and herbs for infusions, for example, by placing some netting over the bottom of the basket.

This small dryer is easy to move and clean.

Nicole Mansard, St. Julien-Chapteuil
